Platform

Total length

8000 mm

Total width

2500 mm

Total height

2390 mm

Axil distance

3050 + 2300 mm

Wheel distance

2071 mm

Total weight

7900 mm

Power

Engine

3.2L Cummins

Cylinder

Six in-line

Rated power

160 KW

Engine can be replaced

150 KW Cummins;

Electricity

Electricity

24V

Driving data

Highest speed

90km/h

Total distance

800km

The main fuel tank

160L

The external tank

60L

Gear and transmission

Clutch

Hydraulic control

Gear box

The connection of transmission and transfer case

Transmission

Hand control

Transfer case

second gear

Traction

Traction device

Towing hook, air and electric socket

Traction device can be replaced

Hydraulic winch, A/C, PTO, ABS, exhaust device

The shortest distance off the ground

440mm

Back rack angle

40·

The smallest turning diameter

13m

Ramp angle

40·

Angle of departure

35·

Perpendicular obstacle height

550mm

Driving side slope

＞40%

Height of the perplex wall to overcome

450mm

Width of the ditch to overcome

750mm

Depth of the water to overcome

900mm

The climbable gradient degree

60%

Tyre

335/80R20

Adaptable environmental temperature

-20℃——46℃

Adaptable altitude height

≥5500m

Adaptable environmental humidity

≥95%

Brake

Two tube brake system

Stationary

Central stationary

Axle and suspension

Front axle and rear axle

Portal axle, hub reduction, differential lock

Suspension

Spiral spring, telescopic shock absorber

Steering

Power Steering
